TECHNICAL SPECIFICATIONS

TEST PERFORMEDTEST STANDARDRESULTS
App. Density Kg/dm3EN 14617-12.2 – 2.45
Water AbsorptionEN 14617-1< 0.04
Flexural Strength (Mpa)EN 14617-250 – 60
Dimension StabilityEN 14617-12Class A
Impact Resistance (Joule)EN 14617-94 – 9 Joule
Compressive Strength (Mpa)
EN 14617-15
170 – 220
Abrasion ResistanceEN 14617-4Groove Length =21.1mm
Frost Resistance
DIN 52104
Compile With Standard

Surface Hardness (Mohs Scale)
EN 101

6.0 – 7.0

Stain ResistanceANSI Z124.6
Pass

Wear & CleanabilityANSI Z124.6
Pass

Chemical Resistance
ANSI Z124.6
Pass

Chemical Resistance
EN 14617-10
Class C4

Resistance To Acids
ASTM C 650
Not Effected

Linear Thermal Expansion (30 – 60)
EN 14617-11
2.6 x 10

Boiling Water Resistance
NEMA LD3-3.5
Pass
High Temprature Resistance
NEMA LD3-3.6
Pass

Cigarette Test
ANSI Z124.6
Pass

Fire Classification
EN 13501-1
Wall Cladding : B-S1-do,
Flooring & Stairs : B-fl-S1
Slip Resistance
EN 14231
Wet:13-21 SRV, Dry : 43-53 SRV

Rediation
GB 6566-2010
Complies With Requirement Of Standard

Thermal Shock Resistance
EN14617-6
No Visual Defects After 10 Cycles
Loss in Flexual Strength =
Loss in Mass = 0.02%-0.05%
0.07%-1.1%
Freeze & Thaw Resistance
EN 14617-5
No Defects After 25 Freeze Thaw Cycles
Glossiness Reflection
%45 – 70

Surface Slip ResistanceHONED 400DIN 51130R9

Static Coefficient Of Friction
ASTM C 1028
Dry : 0.8, Wet : 0.6
